Chapter 642 Vascular Disorders
Vascular lesions of childhood may be divided into vascular birthmarks (malformations and tumors), benign acquired disorders, and genetic diseases. Familial disorders may involve arterial, capillary, lymph, or venous malformations (Table 642-1).
Vascular Birthmark
Vascular birthmarks consist of malformations that are present at birth and tumors, which usually arise in the 1st 2 mo of life.
Vascular Malformation
Vascular malformations are developmental errors in blood vessel formation. Malformations do not regress but slowly enlarge. They should be named after the predominant blood vessel forming the lesion (Table 642-2). Table 642-3 helps differentiate vascular malformations from true hemangiomas.
Table 642-2 VASCULAR MALFORMATIONS
| TYPE | EXAMPLE(S) |
|---|---|
| Capillary | Port-wine stain |
| Venous | Venous malformation |
| Angiokeratoma circumscriptum (hyperkeratotic venule) | |
| Cutis marmorata telangiectasia congenita (congenital phlebectasia) | |
| Arterial | Arteriovenous malformation |
| Lymphatic | Superficial lymphatic malformation (lymphangioma circumscriptum) |
| Deep lymphatic malformation with macrocysts and/or microcysts (cystic hygroma) |
Table 642-3 MAJOR DIFFERENCES BETWEEN HEMANGIOMAS AND VASCULAR MALFORMATIONS
| HEMANGIOMAS | VASCULAR MALFORMATIONS (CAPILLARY, VENOUS, LYMPHATIC, ARTERIAL, AND ARTERIOVENOUS, PURE, OR COMPLEX-COMBINED) | |
|---|---|---|
| Clinical | Variably visible at birth | Usually visible at birth (AVMs may be quiescent) |
| Subsequent rapid growth | Growth proportionate to the skin’s growth (or slow progression); present lifelong | |
| Slow, spontaneous involution | ||
| Sex ratio F:M | 3 : 1 to 5 : 1; 7 : 1 in severe cases | 1 : 1 |
| Pathology | Proliferating stage: hyperplasia of endothelial cells and smooth muscle cell actin–positive cells | Flat endothelium |
| Multilaminated basement membrane | Thin basement membrane | |
| Higher mast cell content in involution | Often irregularly attenuated walls (VM, LM) | |
| Radiology | Fast-flow lesion on Doppler sonography | Slow flow (CM, LM, VM) or fast flow (AVM) on Doppler ultrasonography |
| Tumoral mass with flow voids on MRI | MRI: Hyperintense signal on T2-weighted images when slow-flow (LM, VM); flow voids on T1- and T2-weighted images when fast-flow (AVM) | |
| Lobular tumor on arteriogram | Arteriography of AVM demonstrates AV shunting | |
| Bone changes | Rarely mass effect with distortion but no invasion | Slow-flow VM: distortion of bones, thinning, underdevelopment |
| Slow-flow CM: hypertrophy | ||
| Slow-flow LM: distortion, hypertrophy, and invasion of bones | ||
| High-flow AVM: destruction, rarely extensive lytic lesions | ||
| Combined malformations (e.g., slow-flow [capillary lymphatic venous malformation, Klippel-Trenaunay syndrome] or fast-flow [capillary arteriovenous malformation Parkes-Weber syndrome]): overgrowth of limb bones, gigantism | ||
| Immunohistochemistry on tissue samples | Proliferating hemangioma: high expression of PCNA, type IV collagenase, VEGF, urokinase, and bFGF, Glucose transporter-1 | |
| Involuting hemangioma: high levels of tissue inhibitor of metalloproteinase-1, bFGF | ||
| Hematology | No coagulopathy (Kasabach-Merritt syndrome is a complication of other vascular tumors of infancy, e.g., kaposiform hemangioendothelioma and tufted angioma) | Slow-flow VM, LM, or LVM may have an associated localized intravascular coagulopathy with risk of bleeding (disseminated intravascular coagulation) |
AVM, Arteriovenous malformation; bFGF, basic fibroblast growth factor; CM, capillary malformation/port-wine stain; LM, lymphatic malformation; LVM, lymphovenous malformation; PCNA, proliferating cell nuclear antigen; VEGF, vascular endothelial growth factor; VM, venous malformation.
From Eichenfield LF, Frieden IJ, Esterly NB: Textbook of neonatal dermatology, Philadelphia, 2001, WB Saunders, p 337.
Capillary Malformation (Port-Wine Stain)
Port-wine stains are present at birth. These vascular malformations consist of mature dilated dermal capillaries. The lesions are macular, sharply circumscribed, pink to purple, and tremendously varied in size (Fig. 642-1). The head and neck region is the most common site of predilection; most lesions are unilateral. The mucous membranes can be involved. As a child matures into adulthood, the port-wine stain may become darker in color and pebbly in consistency; it may occasionally develop elevated areas that bleed spontaneously.
True port-wine stains should be distinguished from the most common vascular malformation, the salmon patch of neonates, which, in contrast, is a relatively transient lesion (Chapter 639). When a port-wine stain is localized to the trigeminal area of the face, specifically around the eyelids, the diagnosis of Sturge-Weber syndrome (glaucoma, leptomeningeal venous angioma, seizures, hemiparesis contralateral to the facial lesion, intracranial calcification) must be considered (Chapter 589.3). Early screening for glaucoma is important to prevent additional damage to the eye. Port-wine stains also occur as a component of Klippel-Trenaunay syndrome and with moderate frequency in other syndromes, including Cobb (spinal arteriovenous malformation, port-wine stain), Proteus, Beckwith-Wiedemann, and Bonnet-Dechaume-Blanc syndromes. In the absence of associated anomalies, morbidity from these lesions may include a poor self-image, hypertrophy of underlying structures, and traumatic bleeding.
The most effective treatment for port-wine stains is with the pulsed dye laser (PDL). This therapy is targeted to hemoglobin within the lesion and avoids thermal injury to the surrounding normal tissue. After such treatment, the texture and pigmentation of the skin are generally normal without scarring. Therapy can begin in infancy, when the surface area of involvement is smaller; there may be advantages to treating within the 1st year of life. Although this approach is quite effective, redarkening of the stain may occur 10 yr after therapy. Masking cosmetics may also be used.
Venous Malformation
Venous malformations include vein-only malformation, angiokeratomas (hyperkeratotic venule), and cutis marmorata telangiectasia congenita.
Malformations consisting of veins only run the gamut from nodules containing a mass of venules (Fig. 642-2) to diffuse large vein abnormalities that may consist of either a superficial component resembling varicose veins, deeper venous malformations, or both. Nodular venous malformations are frequently confused with hemangiomas. Venous malformations may be differentiated by their presence at birth, lack of rapid growth phase, and no tendency toward regression. The treatment of choice for superficial nodular vascular malformations is surgical excision. Treatment of larger vein malformations is at best difficult and often impossible. Percutaneous sclerotherapy with direct injection of polidocanol microfoam, with color Doppler ultrasonographic guidance, is helpful in many patients, including those with Klippel-Trenaunay syndrome.
Angiokeratoma Circumscriptum
Several forms of angiokeratoma have been described. Angiokeratomas, characterized by ectasia of superficial dermal vessels and hyperkeratosis of the overlying epidermis, look like flat hemangiomas with a verrucous, irregular surface. Angiokeratoma circumscriptum is a rare disorder consisting of a solitary lesion or multiple lesions that manifest as a plaque or plaques of blue-red papules or nodules with a verrucous surface. The limbs are the sites of predilection. If therapy is desired, surgical excision is the treatment of choice.
Cutis Marmorata Telangiectatica Congenita (Congenital Phlebectasia)
Cutis marmorata telangiectatica congenita is benign vascular anomaly that represents dilatation of superficial capillaries and veins and is apparent at birth. Involved areas of skin have a reticulated red or purple hue that resembles physiologic cutis marmorata but is more pronounced and relatively unvarying (Fig. 642-3). The lesions may be restricted to a single limb and a portion of the trunk or may be more widespread. Port-wine stain may also be associated. The lesions become more pronounced during changes in environmental temperature, physical activity, or crying. In some cases, the underlying subcutaneous tissue is underdeveloped, and ulceration may occur within the reticulated bands. Rarely, defective growth of bone and other congenital abnormalities may be present. No specific therapy is indicated. Mild vascular-only cases may show gradual improvement. Adams-Oliver syndrome and cutis marmorata telangiectatica congenita–macrocephaly syndrome are rarely associated disorders.
Arteriovenous Malformation
Arteriovenous malformations (AVMs) are direct connections of artery to vein that bypass the capillary bed (Fig. 642-4). AVMs of the skin are very rare. They are diagnosed from their obvious arterial palpation. Many physicians mistakenly call all vascular malformations AVMs.
Klippel-Trenaunay and Klippel-Trenaunay-Weber Syndromes
Klippel-Trenaunay syndrome (KT) is a cutaneous vascular malformation that, in combination with bony and soft tissue hypertrophy and venous abnormalities, constitutes the triad of defects of this nonheritable disorder (Fig. 642-5). The anomaly is present at birth and usually involves a lower limb but may involve more than one as well as portions of the trunk or face. Enlargement of the soft tissues may be gradual and may involve the entire extremity, a portion of it, or selected digits. The vascular lesion most often is a capillary malformation, generally localized to the hypertrophied area. The deep venous system may be absent or hypoplastic. Venous blebs and/or vesicular lymphatic lesions may be present on the malformation’s surface. Thick-walled venous varicosities typically become apparent ipsilateral to the vascular malformation after the child begins to ambulate. If there is an associated AVM, the disorder is called Klippel-Trenaunay-Weber syndrome (KTW).
Figure 642-5 Overgrowth of the right arm and hand in and adolescent with Klippel-Trenaunay syndrome.
These disorders can be confused with Maffucci syndrome or, if the surface vascular lesion is minimal, with Milroy disease. Pain, limb swelling, and cellulitis may occur. Thrombophlebitis, dislocations of joints, gangrene of the affected extremity, heart failure, hematuria secondary to angiomatous involvement of the urinary tract, rectal bleeding from lesions of the gastrointestinal tract, pulmonary lesions, and malformations of the lymphatic vessels are infrequent complications. Arteriograms, venograms, and CT or MRI may delineate the extent of the anomaly, but surgical correction or palliation is often difficult. Percutaneous sclerotherapy guided by color echo Doppler ultrasonography is of benefit when a venous component is the dominant vessel in the malformation. The indications for radiologic studies of viscera and bones are best determined by clinical evaluation. Supportive care includes compression bandages for varicosities; surgical treatment may help carefully selected patients. Leg-length differences should be treated with orthotic devices to prevent the development of spinal deformities. Corrective bone surgery may eventually be needed to treat significant leg-length discrepancy.
Phakomatosis Pigmentovascularis
Phakomatosis pigmentovascularis is a rare disorder characterized by the association of a capillary malformation and melanocytic lesions. Typically, the capillary malformation is extensive, and associated pigmentary lesions may include dermal melanocytosis (mongolian spots), café-au-lait macules, or a nevus spilus (speckled nevus). Nonpigmented skin lesions that may occur in this setting include nevus anemicus and epidermal nevi. Systemic anomalies are seen in rare cases.
Nevus Anemicus
Although present at birth, nevus anemicus may not be detectable until early childhood. The nevus consists of solitary or numerous, sharply delineated pale macules that are most often on the trunk but may also occur on the neck or limbs. These nevi may simulate plaques of vitiligo, leukoderma, or nevoid pigmentary defects, but they can be readily distinguished because of their response to firm stroking. Stroking evokes an erythematous line and flare in normal surrounding skin, but the skin of a nevus anemicus does not redden. They can also be diagnosed by diascopy, in which pressure of the skin with a glass slide will obscure the borders of a nevus anemicus. Although the cutaneous vasculature appears normal histologically, the blood vessels within the nevus do not respond to injection of vasodilators. It has been postulated that the persistent pallor may represent a sustained localized adrenergic vasoconstriction.
Vascular Tumor
Vascular tumors include hemangiomas (the most common tumor of childhood), tufted angiomas, kaposiform hemangioendotheliomas, rapidly involuting congenital hemangiomas (RICHs), and non-involuting congenital hemangiomas (NICHs).
Hemangioma
Hemangiomas are proliferative hamartomas of vascular endothelium that may be present at birth or, more commonly, may become apparent in the 1st 2 mo of life, predictably enlarge, and then spontaneously involute. Hemangiomas are the most common tumor of infancy, occurring in 1-2% of newborns (higher in preterm infants) and 10% of white infants in the 1st year of life. Hemangiomas should be classified as superficial, deep, or mixed. The terms strawberry and cavernous should not be used to describe hemangiomas. The immunohistochemical marker GLUT-1 separates hemangiomas from the other vascular tumors of infancy. Superficial hemangiomas are bright red, protuberant, compressible, sharply demarcated lesions that may occur on any area of the body (Figs. 642-6 and 642-7). Although sometimes present at birth, they more often appear in the 1st two months of life and are heralded by an erythematous or blue mark or an area of pallor, which subsequently develops a fine telangiectatic pattern before the phase of expansion. The presenting sign may occasionally be an ulceration of the perineum or lip. Girls are affected more often than boys. Favored sites are the face, scalp, back, and anterior chest; lesions may be solitary or multiple. Patterns of facial involvement include frontotemporal, maxillary, mandibular, and frontonasal regions. Hemangiomas that are more deeply situated are more diffuse and are less defined than superficial hemangiomas. The lesions are cystic, firm, or compressible, and the overlying skin may appear normal in color or may have a bluish hue (Fig. 642-8).
Most hemangiomas are mixed, having both superficial and deep components. Hemangiomas undergo a phase of rapid expansion, followed by a stationary period and finally by spontaneous involution. Regression may be anticipated when the lesion develops blanched or pale gray areas that indicate fibrosis. The course of a particular lesion is unpredictable, but ≈ 60% of these lesions reach maximal involution by 5 yr of age, and 90-95% by 9 yr. Spontaneous involution cannot be correlated with size or site of involvement, but lip lesions seem to persist most often. Complications include ulceration, secondary infection, and, rarely, hemorrhage (Table 642-4). The location of a lesion may interfere with a vital function (e.g., on eyelid interfering with vision, on urethra with urination, on airway with respiration). Hemangiomas in a “beard” distribution may be associated with upper airway or subglottic involvement. Respiratory symptoms should suggest a tracheobronchial lesion. Large hemangiomas may be complicated by coexistent hypothyroidism due to type 3 iodothyronine deiodinase, and symptoms may be difficult to detect in this age group. Other concerning features are listed in Table 642-5.
Table 642-4 COMPLICATIONS OF HEMANGIOMA AND THEIR TREATMENT
| CLINICAL FINDING | RECOMMENDED TREATMENT |
|---|---|
| Severe ulceration/maceration | Encourage twice-daily cleansing regimen |
| Dilute sodium bicarbonate soaks | |
| ± Flashlamp pulsed dye laser | |
| ± Oral corticosteroids or propranolol | |
| ± Culture-directed systemic antibiotics for infection | |
| Bleeding (not KMP) | Gelfoam or Surgifoam or propranolol |
| Compression therapy ± embolization | |
| Hemangioma with ophthalmologic sequelae | Patching therapy as directed by ophthalmologist |
| Intralesional vs oral corticosteroids vs propranolol | |
| Subglottic hemangioma | Oral corticosteroids ± potassium titanyl phosphate (KtP) laser |
| Tracheotomy if required | |
| KMP | Corticosteroids, aminocaproic acid, vincristine, interferon-α ± embolization |
| High-flow hepatic hemangioma | Corticosteroids or interferon ± embolization |
KMP, Kasabach-Merritt phenomenon.
From Blei F: Vascular anomalies: from bedside to bench and back again, Curr Prob Pediatr Adolesc Health 32:72–93, 2002.
Table 642-5 CLINICAL “RED FLAGS” ASSOCIATED WITH HEMANGIOMAS
| CLINICAL FINDING | RECOMMENDED EVALUATION |
|---|---|
| Facial hemangioma involving significant area of face | Evaluate for PHACES (posterior fossa abnormalities, hemangioma, and arterial, cardiac, eye, and sternal abnormalities): MRI for orbital hemangioma ± posterior fossa malformation |
| Cardiac, ophthalmologic evaluation | |
| Evaluate for midline abnormality: supraumbilical raphe, sternal atresia, cleft palate, thyroid abnormality | |
| Cutaneous hemangiomas in beard distribution | Evaluate for airway hemangioma, especially if manifesting with stridor |
| Periocular hemangioma | |
| Paraspinal midline vascular lesion | Ultrasonography or MRI to evaluate for occult spinal dysraphism |
| Hemangiomatosis (multiple small cutaneous hemangiomas) | |
| Large hemangioma, especially hepatic | Ultrasonongraphy with Doppler flow study |
| MRI | |
| Thyroid function studies | |
| Thrill and/or bruit associated with hemangioma | Consider cardiac evaluation and echocardiography to rule out diastolic reversal of flow in aorta |
| MRI to evaluate extent and flow characteristics | |
| Head tilting | Evaluate appropriately for specific site of lesion, and consider physical therapy evaluation |
| Delayed milestones | Consider side effect of corticosteroids (myopathy, weight-related) |
| Consider side effect of interferon (especially spastic diplegia) |
From Blei F: Vascular anomalies: from bedside to bench and back again, Curr Prob Pediatr Adolesc Health 32:67–102, 2002.
In the usual patient with a hemangioma who has no serious complications or extensive growth resulting in tissue destruction and severe disfigurement, treatment consists of expectant observation. Because almost all lesions regress spontaneously, therapy is rarely indicated and may cause further harm. Parents require repeated reassurance and support. After spontaneous involution, many patients are left with small cosmetic defects, such as telangiectasia, hypopigmentation, fibrofatty deposits, and scars if the lesion has ulcerated. Residual telangiectasias may be treated with PDL therapy. Other defects can be treated or minimized by judicious plastic repair if desired.
In the rare case in which intervention is required, if the lesion is very superficial, early therapy with PDL may be beneficial in decreasing growth of the hemangioma. PDL is also useful for the treatment of small (<4-5 cm) ulcerated hemangiomas. Elastic bandages may reduce the amount of tissue distortion resulting from rapid growth, but they are appropriate only in selected patients with large hemangiomas. Rarely, these lesions impinge on vital structures; interfere with functions such as vision, breathing, defecation, urination, or feeding; or cause grotesque disfigurement because of rapid growth.
If further treatment becomes necessary, a course of prednisolone (2-3 mg/kg/24 hr) is effective in most infants. Termination of growth and sometimes regression may be evident after ≈ 2-4 wk of therapy. When a response is obtained, the dose should be decreased gradually. Intralesional corticosteroid injection in the hands of an experienced physician can also induce rapid involution of a localized hemangioma. Propranolol (2 mg/kg) has been used for hemangiomas unresponsive to corticosteroid therapy. Results have been excellent, but exact indications for usage, dosage, length of treatment, and long-term sequelae have not been thoroughly investigated. Hypoglycemia may be a complication of propranolol therapy. Vincristine is used by some oncologists to treat significant hemangiomas. Interferon-α (IFN-α) therapy may also be effective, but spastic diplegia is seen in 10% of cases.
Syndromes associated with hemangiomas include PHACES (posterior fossa brain defects such as Dandy-Walker malformation or cerebellar hypoplasia, large plaquelike facial hemangioma, arterial cerebrovascular abnormalities such as aneurysms and stroke, coarctation of the aorta, eye abnormalities, and sternal raphe defects such as pits, scars, or supraumbilical raphe), Gorham (cutaneous hemangiomas with massive osteolysis), and Bannayan-Riley-Ruvalcaba (macrocephaly lipomas, hemangiomas of autosomal dominant inheritance).
Diffuse Hemangiomatosis
Diffuse hemangiomatosis is a condition in which numerous hemangiomas are widely distributed. The skin usually has many small red papular hemangiomas (Fig. 642-9). Most affected infants have benign neonatal hemangiomatosis, with widespread cutaneous hemangiomas in the absence of apparent visceral involvement. Diffuse neonatal hemangiomatosis is the association of multiple cutaneous hemangiomas of the skin with similar lesions in internal organs. The internal hemangiomas may involve any of the viscera; the liver, gastrointestinal tract, central nervous system, and lungs are the most common sites. In cases of benign neonatal hemangiomatosis, spontaneous regression of the lesions without complications is probable. Infants with diffuse neonatal hemangiomatosis are usually ill at birth. In these cases, ultrasonography and CT are indicated to determine the extent of visceral or neural involvement. The disorder is often fatal because of high-output cardiac failure, visceral hemorrhage, obstruction of the respiratory tract, or compression of central neural tissue. Treatment consists of systemic corticosteroid therapy alone or in combination with vincristine, IFN-α, surgery, or irradiation and support with blood products for erythrocyte, platelet, and coagulation factor consumption.
Tufted Angioma
Tufted angiomas are defined histologically by discrete “cannonball-like” tufts of dermal blood vessels. Two clinical patterns are seen. The classic, more common type is a slowly expanding dusky reddish-blue plaque with satellite lesions. More than 50% of these lesions occur on the head and neck. Regression is not expected. A less common form manifests as a solitary vascular nodule (Fig. 642-10). Clinical differentiation of tufted angioma from a nodular venous malformation is difficult; spontaneous regression of this type of lesion has been reported.
Kaposiform Hemangioendothelioma
Kaposiform hemangioendotheliomas are very aggressive locally and, although not malignant, may be fatal. Lesions are usually solitary, firm, and deep purple in color. They do not spontaneously regress.
Both tufted angiomas and Kaposiform hemangioendotheliomas are difficult to treat. All treatments used for hemangiomas have been tried, and results are extremely variable. Kasabach-Merritt syndrome is seen almost exclusively in patients with tufted angiomas and Kaposiform hemangioendotheliomas.
Kasabach-Merritt Syndrome
Kasabach-Merritt syndrome is a life-threatening combination of a rapidly enlarging tufted angioma or kaposiform hemangioendothelioma, thrombocytopenia, microangiopathic hemolytic anemia, and an acute or chronic consumption coagulopathy. The clinical manifestations are usually evident during early infancy. The vascular lesion is usually cutaneous and is only rarely located in viscera. The associated thrombocytopenia may lead to precipitous hemorrhage accompanied by ecchymoses, petechiae, and a rapid increase in the size of the vascular lesion. Severe anemia due to hemorrhage or microangiopathic hemolysis may ensue. The platelet count is depressed, but the bone marrow contains increased numbers of normal or immature megakaryocytes. The thrombocytopenia has been attributed to sequestration or increased destruction of platelets within the lesion. Hypofibrinogenemia and decreased levels of consumable clotting factors are relatively common (Chapter 478.6).
Treatment involves management of thrombocytopenia, anemia, and consumptive coagulopathy by administration of platelets and by transfusion of red blood cells and fresh frozen plasma. The use of heparinization in this syndrome is controversial but has benefited some patients when combined with transfusions. Treatment of Kasabach-Merritt syndrome includes surgical excision of small lesions, systemic steroids, embolization, radiation therapy, vincristine, aminocaproic acid, cyclophosphamide, pentoxifylline, or recombinant IFN-α. The mortality rate is significant.
Rapidly Involuting Congenital Hemangioma
RICHs, by definition, are present at birth. They manifest as raised violaceous nodules with ectatic veins, as grayish nodules with overlying telangiectasias surrounded by pale rims of vasoconstriction, or as flat infiltrative lesions with violaceous skin. They do not undergo a rapid growth phase, and they involute spontaneously by 1 yr of age.
Noninvoluting Congenital Hemangioma
Like RICHs, the solitary vascular lesions known as NICHs are present at birth. They are round to oval plaques with central or peripheral pallor and coarse overlying telangiectasias. They also do not undergo a rapid growth phase, but they do not spontaneously involute. They are probably better classified as vascular malformations than as tumors.
Benign Acquired Vascular Disorders
Pyogenic Granuloma (Lobular Capillary Hemangioma)
A pyogenic granuloma is a small red, glistening, sessile, or pedunculated papule that often has a discernible epithelial collarette (Fig. 642-11). The surface may be weeping and crusted or completely epithelialized. Pyogenic granulomas initially grow rapidly, may ulcerate, and bleed easily when traumatized because they consist of exuberant granulation tissue. They are relatively common in children, particularly on the face, arms, and hands. Such a lesion located on a finger or hand may appear as a subcutaneous nodule. Pyogenic granulomas may arise at sites of injury, but a history of trauma often cannot be elicited. Clinically, they resemble and are often indistinguishable from small hemangiomas. Microscopically, an early pyogenic lesion resembles an early capillary hemangioma. Collarette formation at the base of the tumor and edema of the stroma may allow differentiation from a capillary hemangioma.
Pyogenic granulomas are benign but a nuisance because they bleed easily with trauma and may recur if incompletely removed. Numerous satellite papules have developed after surgical excision of pyogenic granulomas from the back, particularly in the interscapular region. Small lesions may regress after cauterization with silver nitrate; larger lesions require excision and electrodesiccation of the base of the granuloma. Small (< 5 mm) lesions may be treated successfully with the flashlamp pumped PDL.
Angiokeratoma of Mibelli
Angiokeratoma of Mibelli is characterized by 1- to 8-mm red, purple, or black scaly, verrucous, occasionally crusted papules and nodules that appear on the dorsum of the fingers and toes and on the knees and the elbows. Less commonly, palms, soles, and ears may be affected. In many patients, onset has followed frostbite or chilblains. These nodules bleed freely after injury and may involute in response to trauma. They may be effectively eradicated by cryotherapy, electrofulguration, excision, or laser ablation.
Spider Angioma
A vascular spider (nevus araneus) consists of a central feeder artery with many dilated radiating vessels and a surrounding erythematous flush, varying from a few millimeters to several centimeters in diameter (Fig. 642-12). Pressure over the central vessel causes blanching; pulsations visible in larger nevi are evidence for the arterial source of the lesion. Spider angiomas are associated with conditions in which there are increased levels of circulating estrogens, such as cirrhosis and pregnancy, but they also occur in up to 15% of normal preschool-aged children and 45% of school-aged children. Sites of predilection in children are the dorsum of the hand, forearm, face, and ears. Lesions often regress spontaneously after puberty. If removal is desired, PDL is the mode of choice; resolution is achieved in 90% of cases with a single treatment.
Generalized Essential Telangiectasia
A rare and presumably nevoid anomaly of unknown cause, essential telangiectasia may have its onset in childhood or adulthood. Mild expression consists of patchy retiform telangiectases, particularly on the limbs, with occasional progression to involve large areas of the body surface. The condition must be distinguished from the secondary telangiectasias of connective tissue diseases, xeroderma pigmentosum, poikiloderma, and ataxia-telangiectasia. Treatment with PDL is effective.
Unilateral Nevoid Telangiectasia
An unusual entity, unilateral nevoid telangiectasia is characterized by the appearance of telangiectasia in a unilateral distribution, primarily on the face, neck, chest, and arms. The acquired form occurs most commonly in females at onset of menses or during pregnancy. When initiated by pregnancy, the telangiectasia may fade or disappear postpartum.
Genetic Disorders
Blue Rubber Bleb Nevus
Blue rubber bleb nevus is a syndrome consisting of numerous venous malformations of the skin, mucous membranes, and gastrointestinal tract. Typical lesions are blue-purple and rubbery in consistency; they vary in size from a few millimeters to a few centimeters in diameter. They are sometimes painful or tender. The nodules occasionally are present at birth but usually appear in childhood. New lesions may continue to develop throughout life. Large disfiguring and irregular blue marks may also occur. The lesions, which can rarely be located in the liver, spleen, and central nervous system in addition to the skin and gastrointestinal tract, do not involute spontaneously. Recurrent gastrointestinal hemorrhage due to nevi in the gastrointestinal tract may lead to severe anemia. Palliation can be achieved by excision of involved bowel.
Maffucci Syndrome
The association of numerous vascular and, occasionally, lymphatic malformations with nodular enchondromas in the metaphyseal or diaphyseal portion of long bones is known as Maffucci syndrome. Mutations in the PTH/PTHRP type 1 receptor have been identified in the enchondromatoses. Vascular lesions are typically soft, compressible, asymptomatic blue to purple subcutaneous masses that grow in proportion to a child’s growth and stabilize by adulthood. Mucous membranes or viscera may also be involved. Onset occurs during childhood. Bone lesions may produce limb deformities and pathologic fractures. Malignant transformation of enchondromas (chondrosarcoma, angiosarcoma) or primary malignancies (ovarian, fibrosarcoma, glioma, pancreatic) may be a complication (Chapter 495).
Hereditary Hemorrhagic Telangiectasia (Osler-Weber-Rendu Disease)
Hereditary hemorrhagic telangiectasia (HHT), which is inherited as an autosomal dominant trait, occurs in two types. The gene in HHT-1 encodes endoglin, a membrane glycoprotein on endothelial cells that binds transforming growth factor-β. HHT-2 is caused by mutations in the ACVRL1 gene and is associated with increased risk for hepatic involvement and pulmonary hypertension. Affected children may experience recurrent epistaxis before detection of the characteristic skin and mucous membrane lesions. The mucocutaneous lesions, which usually develop at puberty, are 1- to 4-mm, sharply demarcated red to purple macules, papules, or spider-like projections, each composed of a tightly woven mat of tortuous telangiectatic vessels. The nasal mucosa, lips, and tongue are usually involved; less commonly, cutaneous lesions occur on the face, ears, palms, and nail beds. Vascular ectasias may also arise in the conjunctivae, larynx, pharynx, gastrointestinal tract, bladder, vagina, bronchi, brain, and liver.
Massive hemorrhage is the most serious complication of HHT and may result in severe anemia. Bleeding may occur from the nose, mouth, gastrointestinal tract, genitourinary tract, or lungs; epistaxis is often the only complaint, however, occurring in 80% of patients. Approximately 15-20% of patients with AVMs in the lungs present with stroke due to embolic abscesses. Persons with HHT have normal levels of clotting factors and an intact clotting mechanism. In the absence of serious complications, lifespan of a person with HHT is normal. Local lesions may be ablated temporarily with chemical cautery or electrocoagulation. More drastic surgical measures may be required for lesions in critical sites, such as the lung or gastrointestinal tract. Anemia should be treated with iron.
Hereditary Benign Telangiectasia
A rare disorder, hereditary benign telangiectasia is inherited as an autosomal dominant trait and develops during childhood. The face, upper trunk, and arms are the areas of predilection. The condition is progressive but remains limited to the skin.
Ataxia-Telangiectasia (Chapter 590.1)
Ataxia-telangiectasia is transmitted as an autosomal recessive trait because of a mutation in the ATM gene. The characteristic telangiectasias develop at about 3 yr of age, first on the bulbar conjunctivae and later on the nasal bridge, malar areas, external ears, hard palate, upper anterior chest, and antecubital and popliteal fossae. Additional cutaneous stigmata include café-au-lait spots, premature graying of the hair, and sclerodermatous changes. Progressive cerebellar ataxia, neurologic deterioration, sinopulmonary infections, and malignancies are also seen.
Angiokeratoma Corporis Diffusum (Fabry Disease) (Chapter 80.4)
An inborn error of glycolipid metabolism (α-galactosidase), angiokeratoma corporis diffusum is an X-linked recessive disorder that is fully penetrant in males and is of variable penetrance in carrier females. Angiokeratomas appear before puberty and occur in profusion over the genitalia, hips, buttocks, and thighs and in the umbilical and inguinal regions. They consist of 0.1- to 3-mm red to blue-black papules that may have a hyperkeratotic surface. Telangiectasias are seen in the mucosa and conjunctiva. On light microscopy, these angiokeratomas appear as blood-filled, dilated, endothelium-lined vascular spaces. Granular lipid deposits are demonstrable in dermal macrophages, fibrocytes, and endothelial cells.
Additional clinical manifestations include recurrent episodes of fever and agonizing pain, cyanosis and flushing of the acral limb areas, paresthesias of the hands and feet, corneal opacities detectable on slit-lamp examination, and hypohidrosis. Renal involvement and cardiac involvement are the usual causes of death. The biochemical defect is a deficiency of the lysosomal enzyme α-galactosidase, with accumulation of ceramide trihexoside in tissues, particularly vascular endothelium, and excretion in urine (see Chapter 80.4 for therapy). Similar cutaneous lesions have also been described in another lysosomal enzyme disorder, α-L-fucosidase deficiency, and in sialidosis, a storage disease with neuraminidase deficiency.
